| Model | |
|---|---|
| Model | SEM512 |
| Engine Specification | |
| Emission | China StageII |
| Std Rated Power-Gross | 97.5kW |
| Rated Speed | 2,200r/min |
| Composite Work Cycle Fuel Consumption (l/hour) | 100% of XS122 |
| Ambient Capability-HA Sea Level | 49Deg C |
| Ambient Capability-Cold Weather | -10Deg C |
| Peak Torque/Speed - Gross | 560/1,400-1,600N.m/rpm |
| Sound Level-Spectator | 112dB(A) |
| Sound Level-Operator Position with Cab | 86dB(A) |
| Compaction | 100% of XS122 |
| Operating Specifications | |
| Machine Mass w/Std Config | 12,000 kg Canopy /12,170 kg Cabin / 12,380 kg (Cabin with ROPS) ±3% |
| Weight at Drum w/Std Config | 6,900±3%kg |
| Weight on Rear Axle | 5,100kg |
| Static Linear Load | 310N/cm |
| Max. Grade Ability w/o vibbration | 45% |
| Articulated Angle | 33±1° |
| Turning Radius Inside Drum Edge | 5,990mm |
| Compaction Width | 2,130mm |
| Ground Clearance | 442mm |
| Travel Speed | |
| Lo Range | 0 to 5.5km/h |
| Hi Range | 0 to 12km/h |
| Hydraulic Cycle Time | |
| Full Turn Time | 6±0.5s |
| Vibratory System | |
| Freqency-Hi/Lo | 33HZ/30HZ |
| Amplitude-Hi/Lo | 1.80mm/0.90mm |
| Centrifugal Force-Hi/Lo | 245kN/150kN |
| Dimensions | |
| Machine Dimensions[L*W*H] | 5,815*2,290*3130mm |
| Oscillation Angle | 10±1° |
| Wheelbase | 2,900mm |
| Tread Width | 1,600mm |
| Drum Width | 2,130mm |
| Drum Diameter | 1,600mm |
| Tire Specs | |
| Tire Specs | 23.1-26 12PR12 |
| Tire Pressure Setting | 0.35Mpa |
| 注释：产品参数可能因不同国家规定或配置有所不同，以上信息仅供参考，详细信息请联系当地经销商。 | |
